PP-9812W

    22 inch
    Chipset : Intel® N150
    Inquiry

    Quick find
    proimages/product-detail/10-XPPC/P1_top.png
    proimages/product-detail/10-XPPC/P1_bottom.png
    Specification.
    XPPC Series PP-9815 / PP-9815W / PP-9812W
    FEC
    PlatformWindowsWindowsWindows
    Model
    PP-9815
    15 "
    PP-9815W
    15.6 "
    PP-9812W
    21.5 "
    System
    Processor Intel Processor TwinLake N150 / i3-N35501
    Memory 1 x 8GB DDR5 SO-DIMM (Standard), up to 16 GB02
    Storage 1 x 128 GB M.2 2280 SSD (PCIe Gen 3 x4, Standard), up to 512 GB03
    Operating System Windows 11 / Windows 11 IoT Enterprise / Windows 11 Pro / Linux by Request04
    Display
    Display 15 inch XGA (1024 x 768) 15.6 inch Full HD (1920 x 1080) 21.5 inch Full HD (1920 x 1080)
    Brightness 350 nits / 500 nits 350 nits / 500 nits 250 nits / 500 nits
    Touch Projected capacitive (P-CAP)
    Audio
    Speaker 2 x 2 W speakers
    Connectivity
    Wi-Fi Wi-Fi 6E05
    Bluetooth Bluetooth 5.2
    Camera 2MP Camera
    Mic Microphone
    External I/O
    External I/O 1 x RJ11 (Cash Drawer)1 x RJ45 (COM)2 x USB 2.0 Type-A2 x USB 3.0 Type-A1 x Gigabit LAN1 x DisplayPort++1 x Smart DD / USB-C PD & DP1 x DC-in1 x Smart I/O
    Universal I/O 1 x Powered USB 24V1 x Powered USB 12V1 x RS-2322 x USB 2.0 Type-A1 x Second LAN1 x Audio
    Smart I/O DB9 (RS-232) portDC-out 12VPowered USB 12VUSB 2.0 Type-B + DC-out 24V (3-pin)USB 2.0 Type-A + DC-out 12VUSB 3.0
    Add-on device
    (Optional)    		 MSRFingerprint ReaderiButtonRFIDMSR + RFID (2-in-1)
    Power
    Power 65W (19V) / 90W (20V) / 130W (20V) Power Adapter
    Mechanical
    Mounting VESA 100 x 100 mm
    Construction Aluminum Die-Casting + Plastic
    Color Galaxy Gray
    Environmental
    Operation Temperature 0°C - 40°C / 32 to 104 °F
    Storage Temperature -20°C - 60°C / -4 to 140 °F
    Compliance
    Certifications FCC / CE / Class B
    Ingress Protection (IP Rating) IP65 (Front Panel)06
    Shipping
    Dimension 342 x 273 x 34.5 mm13.46 x 10.75 x 1.36 in 368.2 x 253.3 x 30.6 mm14.50 x 9.97 x 1.20 in 512.3 x 308.9 x 45 mm20.16 x 12.16 x 1.77 in
    Net Weight 3.92 kg / 8.64 lb 3.42 kg / 7.54 lb 5.5 kg / 12.13 lb
    Carton Subject to packaging configuration.
    Gross Weight Subject to packaging configuration.
    FEC campaign visual

    Packaging Dimensions / Packaging Weight:Packaging dimensions and weight are approximate and may vary depending on packaging configuration,production batch, and shipping requirements.

    Specifications are subject to change without notice.

    note
    01 Performance, thermal behavior, and power consumption may vary by CPU configuration.
    02 Memory capacity and supported configurations may vary by model and project requirements.
    03 Storage capacity is defined as 1 GB = 10⁹ bytes and 1 TB = 10¹² bytes. Actual formatted capacity will be less.
    04 Supported operating systems are limited to the versions listed above. Other operating systems are not validated.
    05 Wi-Fi 6E availability varies by region and local certification.
    06 Ingress protection applies to the front panel only under specified test conditions.
