• XPPC continues the XPOS's DNA, keep it slim and dual-hinge design.
  • Using Intel Elkhart Lake 10th Generation Processor & Support High-speed PCIe M.2 SSD.
  • Adjustable angle and height improve the viewing angle, enhance the user experience, can also be Desktop, Pole or Wall-mounted.
  • Easy for maintenance: Easy to access DRAM/ SSD/ MB.
  • Shared Peripherals: Share the same peripherals with XPOS.

proimages/Web_Data/product/05-Panel_PC/PP-9715/PP-9175_fea.jpg
01

ECO-FRIENDLY

Reduce the size and package to save the environment and for easier transportation

02

WITH PAYMENT EFT / SCANNER

Two ways for add-on device settlement.

Arm type Barcode Scanner

Payment Device

RFID Device

03

2nd Display

Arm / Pole Type for different countertop

04

S E N S O R

Ambient light sensor allows system automatically adjust the brightness of the screen according to the environment.

05

Processor J6412

Fanless CPU For Complex solution.


Specifications

CPU
CPU
  • Intel® Celeron® J6412 1.5M Cache, 2.60GHz
Memory
Memory
  • 4GB Standard, Max 32GB (1 x So-DIMM DDR4)
Storage
Storage
  • 1 x M.2 M Key (SATA III or PCIe)
Connection
Connection
  • 1 x M.2 E Key 802.11ac + BT (Optional)
Speaker
Speaker
  • 2 x 2W Internal Speaker
Display
Display
  • 15.6" TFT, 1920 x 1080
Touch
Touch
  • True-Flat PCAP
Brightness
Brightness
  • 300 nits
Camera
Camera
  • 2MP Front Camera (Optional)
Power
Power
  • 20V / 90W or 130W External Adapter
OS
OS
  • Windows 10 Enterprise (LTSC, SAC)
  • Windows 11 IoT Enterprise (Est. available in Q3 2023)
  • Linux
TPM
TPM
  • TPM2.0: Intel PTT
Mounting
Mounting
  • VESA 100 x 100 mm
Certification
Certification
  • FCC / CE Class B
Appearance
Appearance
  • Aluminum Die-Casting + Plastic
  • Galaxy Grey + Silver
Temperature
Temperature
  • Operation: 0˚C ~ 40˚C (32˚F ~ 104˚F)
  • Storage: -20˚C ~ 60˚C (-4˚F ~ 140˚F)
Dimensions (W x H x D)
Dimensions (W x H x D)
  • Product: 368 x 272.5 x 315 mm
  • Carton: 492 x 168 x 488 mm
Weight
Weight
  • Net 3.92 KG,
  • Gross 6.7 KG
Port
Port
  • 1 x RJ11 (12V / 24V) Cash Drawer
  • 2 x RJ45 (COM1, COM2) RS232
  • 4 x USB Type A ( 3 x USB 2.0, 1 x USB 3.0)
  • 1 x RJ45 GigaLAN
  • 1 x Video Port
  • 1 x 20V DC-In
  • 1 x Smart DD
  • 1 x Smart I/O (Reserved for additional DC output 5V/12V/24V, USB, or Com ports)
Optional
Optional
  • Universal I/O (Select 1 from below)
    1 x PUSB 24V
    1 x PUSB 12V
    1 x RJ45 (COM) RS232
    2 x USB 2.0 TypeA
