KP Series | Industrial Touchscreen for High-Demand Kitchens

Resilience Through Heat, Precision Under Pressure

加入比較

快速連結

特點
規格
相關信息
案例分享

proimages/Web_Data/product/11-KP/LNEW/15U.png

proimages/Web_Data/product/11-KP/LNEW/15D.png

Specification.

KP Series KP-9795W / KP-9155W

Platform	Windows	Android
Model	KP-9795W 15.6 "	KP-9155W 15.6 "
System
Processor	Intel N97 / N150 / Core 3 N35501	MTK G700
Memory	1 x DDR4 SO-DIMM Socket (Standard 4G, up to 16GB)02	1 x DDR4 8G on Board
Storage	1 x M.2 2280 SSD PCIe Gen 3x4 (Standard 128G, up to 512G)03	1 x eMMC 64G on Board03
Operating System	Windows 10 IoT Enterprise / Windows 10 Pro / Windows 11 IoT Enterprise / Windows 11 Pro / Linux by Request04	Android 14
Display
Display	15.6" TFT, 1920 x 1080
Brightness	350 / 500 nits
Touch	P-CAP (Support Water-resistant & Glove Mode)
Audio
Speaker	2 x 2W
Connectivity
Wi-Fi	Wi-Fi Module (Internal)
External I/O
External I/O	1 x 19V DC-in1 x RJ45 GIGA LAN (Support PoE Function)3 x USB 2.0 Type-A1 x USB 3.0 Type-A1 x RJ45 COM (RS232)	1 x 19V DC-in1 x RJ45 GIGA LAN (Support PoE Function)3 x USB 2.0 Type-A1 x USB 3.0 Type-A1 x SD Card Slot1 x USB OTG Type-C1 x Recovery Button
Add-on device (Optional)	ScannerRFIDLED BarCamera
Power
Power	19V / 65W Adapter
Mechanical
Mounting	VESA 75 x 75 mm
Construction	Aluminum Die-Casting + Plastic
Color	Grey
Environmental
Operation Temperature	0°C - 50°C / 32 to 122 °F
Storage Temperature	-20°C - 60°C / -4 to 140 °F
Compliance
Certifications	FCC, CE Class B
Ingress Protection (IP Rating)	IP54 (All-Device)
Shipping
Dimension	361.7 x 219.7 x 14.5 mm14.24 x 8.65 x 0.57 in
Net Weight	2.8 kg / 6.17 lb	2.7 kg / 5.95 lb
Carton	Subject to packaging configuration.
Gross Weight	Subject to packaging configuration.

Packaging Dimensions / Packaging Weight:Packaging dimensions and weight are approximate and may vary depending on packaging configuration,production batch, and shipping requirements.

Specifications are subject to change without notice.

note

01 Performance, thermal behavior, and power consumption may vary by CPU configuration.

02 Memory capacity and supported configurations may vary by model and project requirements.

03 Storage capacity is defined as 1 GB = 10⁹ bytes and 1 TB = 10¹² bytes. Actual formatted capacity will be less.

04 Supported operating systems are limited to the versions listed above. Other operating systems are not validated.
