01

Two Height of Your Choice

02

No Worry About Understaffed

XP-4685B can be rotated 180 degrees and turn into Kiosk mode.

03

Intergration Base

Hidden all cable and adapter under the base and with fanless and cooling desing, no worry about overheat.

Specifications

CPU
CPU
  • Intel® Celeron® 3965U 2M Cache, 2.20 GHz
  • Intel Core™ i3 7100U 3M Cache, 2.40 GHz
  • Intel Core™ i5 7300U 3M Cache, up to 3.50 GHz
Memory
Memory
  • 4GB Standard, Max 32GB (2 x So-DIMM DDR4)
Storage
Storage
  • 2 x M.2 M Key (SATA III or PCIe)
  • *(Celeron® Supports Only One PCIe Storage Device )
Connection
Connection
  • 2 x M.2 E Key 802.11ac + BT (Optional)
Speaker
Speaker
  • 2 x 2W Internal Speaker
Display
Display
  • 15.6” TFT , 1920 x 1080
Touch
Touch
  • True-Flat PCAP
Brightness
Brightness
  • 400 nits
MTBF
MTBF
  • 50K Hours
Camera
Camera
  • 2MP Front Camera (Optional)
Power
Power
  • 20V / 90W or 20V / 130W External Adapter
OS
OS
  • Windows 10 Pro
  • Windows 10 IoT Enterprise
Mounting
Mounting
  • VESA 100 x 100 mm
Certification
Certification
  • FCC / CE Class B
Appearance
Appearance
  • Aluminum Die-Casting + Plastic
  • Black
Temperature
Temperature
  • Operation: 0˚C ~ 40˚C (32˚F ~ 104˚F)
  • Storage: -20˚C ~ 60˚C (-4˚F ~ 130˚F)
Dimensions (W x H x D)
Dimensions (W x H x D)
  • Product: 295 x 197 x 350 mm
Weight
Weight
  • Net: 4 Kg
  • Gross: 5 Kg
Port
Port
  • 1 x USB 3.0 Type A
  • 1 x USB 2.0 Type A (Reserved for Add-On)
  • 1 x USB DP (Reserved for 2nd Display)
  • 1 x Smart DP ( Reserved for Customer Display or 2nd Display)
I/O on Base
I/O on Base
  • 2 x RJ45 (COM3, COM4) RS232
  • 4 x USB 2.0 Type A
  • 1 x USB DP (2nd Display)
  • 1 x RJ11 (12V / 24V)
  • 1 x RJ45 LAN
  • 1 x 20V DC-in
